Description
For use with Rocket Bunny Version 2 Front Bumper on FR-S/BRZ, RX-7, 350Z, GT-R, S15 and NSX
10 LED DRL Light Kit with controller
Basic Wiring Diagram Translation:
- Black (-)- Ground
- Red (+)-12V Power
- Yellow- 12V ACC
- White- 12V Positive Headlight
- Gray-12V to Flash Blinker
- Brown- 12V Blinker Set A LED
- Green- 12V Blinker Set B LED
Product description:
With ACC at ON position, the light will light up WHITE
Corresponding LED will flash AMBER with turn signal on
With parking or headlights on, the LED will turn AMBER
It will take roughly 20sec for the LED to turn off after the ACC is turned OFF
* Flash Feature: if you connect the Gray wire to positive terminal, the LED will flash WHITE and AMBER
Input Voltage: DC 9V-24V
Current Draw: 0.7A per unit
Waterproof rating: IP66
* Make sure to check that all the LEDs light up before installation
Detailed Wiring Instructions:
- Connect the main unit (control box) to the LED(s)
- Connect the Yellow wire to the Positive batter terminal and the Black wire to the Negative. – LED will light-up WHITE
- Connect the White wire to Positive battery terminal. LED will light up AMBER
- Connect the Brown or Green wire to 12V source. Each corresponding LED will light up AMBER
- If you disconnect the Yellow wire from the 12V source.LED will turn off after 20sec.
- If you connect the Gray wire to the 12V source while the LED is on – the LED will Flash.
Specification
- Part Type: Daytime Running Lights
- Color: Clear
